    Nema 34 8.5NM 86mm Closed Loop Servo Motor Hybrid

    Ask Lasest Price
    Brand Name : Jkongmotor
    Model Number : JK86HSN85
    Certification : CE, ROHS,ISO9001
    Price : US $72.50 - US $88.50
    Payment Terms : T/T , paypal , Western Union, L/C
    Supply Ability : 50000pcs/month
    Delivery Time : For samples , 7-25 days / For batch , 15-40days
    • Product Details
    • Company Profile

    Nema 34 8.5NM 86mm Closed Loop Servo Motor Hybrid

    Closed Loop Stepper Motor Nema 17 Bipolar Stepping Motor With Encoder

    8.5N.m Nema34 Closed loop Motor + driver full kit:


    1) Product Name: 8.5N.m Nema34 Closed loop servo stepper motor

    Model: JK86HSN85

    Number of Phase: 2

    Step Angle: 1.8 Degree

    No. of Leads: 4

    Rated Voltage: 2.52V

    Rated Current: 6.0 Amps

    Holding Torque: 8.5N.m

    Motor Diameter: 86mm

    Motor length:143.5mm

    Shaft Length: 37mm

    Shaft Diameter: 14mm


    2) Product Name: 8.5N.m Nema34 Closed loop servo stepper driver

    Model:JK-HSD86

    Voltage Range: 30-110VDC, 20-80VAC

    Microstep/pulse: 51200/rev


    3)Typical applications: CNC machine


    Electrical Specification:
    Closed Loop Servo Stepper Motor / Easy Servo Stepper Motor Series
    Motor seriesPhase No.Step angleLeads No.Motor sizeHolding Torque
    Nema 232 phase1.8 degree457x57mm1.8N.m
    Nema 232 phase1.8 degree457x57mm2.2N.m
    Nema 232 phase1.8 degree457x57mm3.1N.m
    Nema 242 phase1.8 degree460x60mm3.1N.m
    Nema 242 phase1.8 degree460x60mm4.0N.m
    Nema 342 phase1.8 degree486x86mm4.5N.m
    Nema 342 phase1.8 degree486x86mm8.5N.m
    Nema 342 phase1.8 degree486x86mm12N.m
    Nema 423 phase1.2 degree4110x110mm20N.m
    Nema 523 phase1.2 degree4130x130mm30N.m
    Above only for representative products, products of special request can be made according to the customer request.

    Details of 86mm closed loop servo motor:

    Drawing of Hybrid servo stepper motor:

    Introdution of JKONGMOTOR:

    Nema 34 8.5NM 86mm Closed Loop Servo Motor HybridNema 34 8.5NM 86mm Closed Loop Servo Motor Hybrid

    Nema86 stepper motor Application:

    Nema 34 8.5NM 86mm Closed Loop Servo Motor HybridNema 34 8.5NM 86mm Closed Loop Servo Motor HybridNema 34 8.5NM 86mm Closed Loop Servo Motor HybridNema 34 8.5NM 86mm Closed Loop Servo Motor Hybrid

    FAQ:


    Q: 1. Can you make the gearbox or gearmotor with custom specifications?
    A: YES. We have strong R&D capability, also a great term of engineers, each of them have many work years experience.

    Q: 2. Do you provide the samples?
    A: YES. Our company can provide the samples to you

    Q:3.Do you provide technology support?
    A: YES. Our company have strong R&D capability, we can provide technology support if you need.

    Q: 4. why should you buy from us not from other suppliers?
    A: Professional one-to-one motor customized . The world's large enterprise of choice for high quality suppliers . ISO9001:2008 quality management system certification, through the CE, ROHS certification.

    Q: 5. How to ship to us?
    A: We will ship the samples to you according to the DHL or UPS or FEDEX etc account you provide.

    Q: 6. How can I know the product is suitable for me?
    A: Frist, you need to provide us the more details information about the product. We will recommend the item to you according to your requirement of specification. After you confirm, we will prepare the samples to you. also we will offer some good advances according to your product use.
